ASUS VW222S 22"

Display ASUS VW222S 22"

Display diagonal

Size of the display for this product, measured diagonally, usually in inches.

55.9 cm (22")

Display resolution

The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.

1680 x 1050 pixels

Touchscreen

A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.

Display brightness (typical)

Display brightness, measured by its Luminance, presented as a figure in nits. Typical brightness ratings for monitors range from 250 to 350 nits with a target value of between 80 to 120 nits being suitable for most displays in a normal viewing environment.

300 cd/m²

Response time

The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.)

2 ms

Contrast ratio (typical)

The difference in light intensity between the brightest white and the darkest black.

2000:1

Viewing angle, horizontal

Maximum horizontal angle at which a display can be viewed with acceptable visual performance.

170°

Viewing angle, vertical

Maximum vertical angle at which a display can be viewed with acceptable visual performance.

160°

Pixel pitch

This is the parameter of a picture tube, which specifies the shortest distance between two dots of the same colour. The principle is: the smaller the dot pitch, the better sharpness of image.

0.282 x 0.282 mm

Horizontal scan range

31.3 - 80.2 kHz

Vertical scan range

56 - 75 Hz

Multimedia

RMS rated power

RMS (Root mean square) is a measure of the continuous power required by a device, in particular audio amplifiers and loudspeakers.

2 W

Design

Product colour

The colour e.g. red, blue, green, black, white.

Black

Ports & interfaces

VGA (D-Sub) ports quantity

Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM.

1

PC Audio in

The socket (port) for the PC audio input.

AC (power) in

Ergonomics

Panel mounting interface

The product can be used wih VESA mounting interfaces.

100 x 100 mm
