Pixfra Mile 2 Pfi-M215M 256x192 15mm 1x-8x 50Hz Wi-Fi

NEW!
Super compact pocket thermal monocular.

Pixfra Mile 2 Pfi-M215M 256x192 15mm 1x-8x 50Hz Wi-Fi thermal camera.

Thermal Monocle Mile 2 Series

Integrated compact design

Pocket-size compactness is combined with an ergonomic design for portability and ease of use over extended periods of time.

A BRIGHT VISUAL UPGRADE!

Enjoy unparalleled image quality with an advanced 25-megapixel NETD sensor and ultra-high-resolution 640p lens, complemented by a wide color gamut P3 AMOLED screen and 20x eyepiece.

VERSATILE WEARING OPTIONS FOR ALL SCENARIOS!

A variety of skin-friendly accessories such as a soft case, neck strap and wrist strap make it comfortable to use. Its centralized design eliminates tipping when worn around the neck.

INNOVATIVE BUTTON LAYOUT!

Ideal for nighttime use, allowing seamless operation of the blinds, enhancing the one-handed user experience and meeting the needs of use in dark environments.

ALWAYS READY TO WORK!

Long battery life of 8-10 hours for overnight use.

EASY SHARING!

Stay connected effortlessly with stable WiFi for real-time monitoring of 4 people.

SPECIFICATIONS

Product model PFI-M215M

Detector type Vanadium oxide uncooled focal plane detector

Effective pixels 256 (H) × 192 (V)

Pixel pitch 12 μm

Spectral range 8 μm14 μm

Sensitivity (NETD) ≤35 mKf/ 1.0

Frame rate 50 Hz

Focal length 15 mm

Field of view H: 11, 7; V: 8, 8/ H: 20, 5 m; V: 15, 4 m (100 m)

Manual focus control

Reception range 800 m (2624, 67 ft)

Magnification 2, 33 ×

Colour palette 6 (white hot/ black hot/ yellowish red/ warning signal/ amber/ amber brown)

Close focusing distance 2, 6 m (8, 53 ft)

Aperture F1, 0

Digital zoom 1 ×; 2 ×; 4 ×; 8 ×

Display screen size 0, 32 inches, OLED

Screen resolution 800 (H) × 600 (V)

Dioptric -3D to +1D

Eye opening 13 mm

Uniformity correction Automatic; manual

Storage Built-in EMMC (16 GB)

Hotspot tracking yes

Wi-Fi yes

Analog output Yes, Type C

Power supply 5 VDC/ 2 A, USB Type-C

Battery type Rechargeable lithium battery

Battery capacity 3200 mAh

Battery life ≥8.5 h

Operating temperature -30 C to +55 C (-22 F to +131 F)

Storage temperature -40 C to +70 C (-40 F to +158 F)

Protection IP67

Product dimensions 155.3 mm × 56.6 mm × 50.3 mm (6.12" × 2.23" × 1.98") (L × W × H)

Package dimensions 180 mm × 123 mm × 96 mm (7.09" × 4.84" × 3.78") (L × W × H)

Net weight <270 g (0,60 lb)
