Põrandakütte ajam 230V

Salus T30NC230

T30NC230 - Electro Thermal Actuator

Characteristics

• First open function for ease of installation
• Adaptive stroke length 4mm
• Low Power consumption 2W
• 100N Force
• High quality wax element
• Simple open and close indication
• Universal M30 x 1.5mm screw thread
• 5 year warranty

Features

T30NC230 is a thermal actuator for energy saving, used to regulate surface heating and cooling systems.

Product Information

Product: Electro Thermal Actuator
Operation mode: NC = Normally Closed
N: Neutral Connection
L: 230V Live Connection
Dimensions (mm): 40 x 60 x 42

Technical Data

Model: T30NC230 / T28NC230 / T30NC24
Power Supply: 230V AC 50 Hz / 24V AC/DC
Imax: 200 mA / 200 ms 250 mA / 120 s
Working Power Consumption: 2 W
Type: NC = Normally Closed
Force: 100 N (±10%)
Opening/Closing Time: approx. 2 min
Stroke Length: 4 mm
Thread: M30x1.5 / M28x1.5
Dimensions (mm): 40 x 70 x 40
Cable Length (cm): 89

Connection Scheme

L - AC 230V
N - Neutral Connection
Battery powered thermostat
L N SL - AC 230V
230V Regulator
