Waves / PRS GTR Guitar Interface

Waves / PRS GTR Guitar Interface

new

SPECIFICATIONS
PRS Guitar Interface
• Dimensions: 9.5cm (W) x 4.3cm (H) x 11.5cm (D)
• Weight: 356g
•
• TRS input
• Input impedance: >1 Mega Ohm unbalanced
• Max input level: 1.1 VRMS.
• Power saving switch: Automatic shut down when input jack is not connected
•
• Balanced XLR input
• All measurements were performed with volume at a nominal setting
• Output impedance: 50 ohm
• S/N: >105 at line level, (S measured at 1%, 1kHz, A-weighted)
• Response: 20-20kHz, -3dB @ 11kHz, -5dB at 20kHz
• THD+N: <0.005 (< -90dB) at -10dB below max sensitivity level
• Sensitivity: 1.1Vrms at line level, 2.5 Vrms at mic Level
• Gain: 11dB at line level, -28dB at mic level. ±1.5dB
• Volume range: +5dB, -10dB refer to nominal setting
• Output short circuit protection: Ground lift switch
• Power: Two 9V Batteries, 12-18V DC, 0.5A minimum
•
• Unbalanced PL Jack output
• All measurements were performed with volume at a nominal TD setting
• Output impedance: 50 ohms
• S/N: >105 at line level, (S measured at 1%, 1kHz, A-weighted)
• Response: 20-20Khz, -3dB at 11kHz, -5dB at 20kHz
• THD+N: <0.005 (< -90dB) at -10dB below max sensitivity level
