Yamaha AW1600 16-Track Hard Disk Recorder

Müüa väga heas korras Yamaha AW1600 16-Track Hard Disk Recorder. Yamaha's groundbreaking AW16G and AW4416 digital audio workstations not only brought the "studio in a box" concept directly to musicians -- they also provided immediate access to inspiration and creativity. That legacy continues with the introduction of the AW1600 and AW2400 workstations. The AW1600 and AW2400 have everything needed to record your music anytime, anywhere in compact, road-worthy designs. The AW1600 adds many features to the award-winning AW16G while maintaining the same affordability. These new features include 8 combo inputs (all with Phantom power), USB 2.0 drag and drop capabilities for moving files onto your computer, 24-bit recording and a new Pitch Fix algorithm for correcting the pitch of vocal tracks.
The Mobile Musicians Recording Studio
If youre a musician on the move - or with limited "studio" space - youll want maximum audio workstation performance and functionality with minimum size, weight, and setup hassles. The AW1600 proves extraordinary music production power in a remarkably compact, all-in-one unit that can take you all the way from inspiration to finished CD.
Features:
8-input/16-track system records top-quality uncompressed 16-bit or 24-bit audio at 44.1 or 48 kHz (8 tracks when recording 24-bit audio)
8 virtual tracks per physical track (18 x 8 in 16-bit mode) provide plenty of capacity for alternate takes
Substantial 40-gigabyte high-speed 3.5 in. hard disk provides plenty of internal storage as well as fast, reliable recording and playback performance
Built-in CD-RW drive lets you burn original audio CDs that can be played on any standard CD player, as well as make reliable CD data backups
High-performance 24-bit A/D and D/A converters guarantee outstanding audio quality
4-band EQ and versatile dynamics processing on all mixer inputs and recorder tracks
8 combo XLR/TRS microphone/line inputs, with switchable phantom power for all connectors
Hi-Z mono phone jack on input 8 for direct guitar input
Quick loop sampler with preset rhythm phrases
Sound Clip function makes it simple to record short audio samples or memos
2 high-performance assignable effect processors provide a range of ambience, modulation, mastering, and even guitar effects
Pitch Fix function allows precise vocal pitch correction
USB 2.0 interface provides fast data transfer between the AW1600 and a computer for effective data management
Data compatibility with the Yamaha AW4416, AW2816, and AW16G audio workstations

Internal Processing : 32bit
Sampling Frequency : 44.1kHz (-6% ~ +6%)
Frequency Response: 0, +1 / -3 dB, 20Hz – 20kHz, ref to the nominal output level @1kHz
(MIC / LINE INPUT – STEREO / AUX OUT, GAIN min)
Total Harmonic Distortion Fs = 44.1kHz : Less than 0.03% @1kHz / -10dBV
(MIC / LINE INPUT – STEREO / AUX OUT, GAIN min)
* Total Harmonic Distortion is measured with 20kHz LPF
Dynamic Range :
– 109 dB typ. DA Converter (STEREO / AUX OUT),
– 103 dB min. DA Converter (STEREO / AUX OUT), (INPUT CH all off)
– 103 dB typ. AD+DA (MIC / LINE INPUT to STEREO / AUX OUT)
– 97 dB min. AD+DA (MIC / LINE INPUT to STEREO / AUX OUT), (GAIN min)
* Dynamic range is measured with IHF-A filter

Crosstalk@1kHz : -70 dB
Phantom Voltage : 48V
AD Converter : 24 Bit Linear / 64 Times Oversampling
DA Converter : 24 Bit Linear / 128 Times Oversampling
MIDI : MTC (Master / Slave), MIDI Clock (Master), MMC (Master / Slave), Program Change, Control Change
Memory : Scene Memory, EQ Library, Dynamics Library, Effect Library
Fader : 13 x 60mm
Display : 240 x 64 dot GRAPHIC LCD (contrast control pot.)
AC Adaptor : PA-300
Dimensions (W x D x H) : mm 455 x 349 x 107
Net Weight : 6.2kg
Operating Temperature : 5~35°C

MIXER SPECIFICATIONS

Audio Input Section : MIC / LINE INPUT
DIGITAL STEREO IN : 8 CH (COMBO XLR+PHONE)
2 CH (COAXIAL STEREO x 1)
Audio Output Section :
MONITOR OUT – 2 CH (STEREO x 1)
PHONES – 2 CH (STEREO x 1)
STEREO / AUX OUT – 2 CH (STEREO x 1)
DIGITAL STEREO OUT – 2 CH (COAXIAL STEREO x 1)
Mixer Input Section: Total 36 CH
MIC / LINE INPUT – 8 CH
INTERNAL EEEFECT RETURN -4 CH (STEREO x 2)
RECORDER MONITOR – 16 CH
QUICK LOOP SAMPLER – 8 CH (STEREO x 4)
Internal Effect Section:
EFFECTS – 2 Units
Master Section : Total 8 Bus
BUS – 2 CH (STEREO x 1)
AUX – 2 CH
STEREO -2 CH (STEREO x 1)
EFFECT – 2 CH

RECORDER SPECIFICATIONS:
Recording Resolution – 16bit / 24bit
Sampling Frequency – 44.1kHz
Maximum Number of Songs – 100 songs
Maximum Number of Simultaneous Recording / Playback Tracks:
8 Tracks Recording (16bit)
8 Tracks Recording (24bit)
16 Tracks Playback (16bit)
8 Tracks Playback (24bit)
Number of Tracks – 144 Tracks (16 Tracks + STEREO Track) x 8 Virtual
HDD : Type – 3.5″IDE, Capacity – 40GB
Edit Functions :
Song Edit – OPTIMIZE, DELETE, COPY, IMPORT
Track Edit – ERASE, DELETE, INSERT, COPY, MOVE, EXCHANGE,
TIME COMP / EXPAND, PITCH CHANGE, EXPORT, CD IMPORT, WAV IMPORT
Other Functions :
LOCATE – Quick LOCATERTZ, A, B, LAST REC IN, LAST REC OUT
PUNCH I / O – MARK1~99
PITCH FIX – MANUAL PUNCH I / O, AUTO PUNCH I / O
CD-RW DRIVE – DATA BACKUP, CD-AUDIO MAKEUP and PLAYBACK, CD-AUDIO IMPORT, WAV FILE IMPORT

Pildid on originaal seadmest. Tule kohale ja kuula ise . Garantii ja hilisem vahetusvõimalus, kohale toimetamine üle Eesti. Tingimisvõimalus kohapeal olemas! Helista ja küsi lisa. Vaata ka meie teisi kuulutusi. Asume- Tallinn, Kesklinn, Türi 6, Tallinn ,Türi 6 Kabinet 75 a korpus peauksest
