Новый гибридный инвертор 3.5kW нового поколения

Müüa uus hübriidinverter. 3.5kW, uus generatsioon, ehk ei vaja töötamiseks/tööle minemiseks akusid. Ei ole pakendist välja võtnud.

Specifications:

Brand

DAXTROMN

Model

GGH-3.5KW

Rated Power

3500VA/3500W

AC Input

Voltage

230VAC

Selectable Voltage Range

170～280VAC(For Personal Computers)

90～280VAC(For Home Appliances)

Frequency Range

50Hz/60Hz(Auto sensing)

AC Output

AC Voltage Regulation(Batt.Mode)

230VAC±5%

Surge Power

7000VA

Efficienc(Peak)PV to INV

97%

Efficienc(Peak)Battery to INV

94%

Transfer Time

10ms(For Pensonal Computers);

20ms(For Home Appliances)

Battery & AC Charger

Battery Voltage

24VDC

Floating Charge Voltage

27VDC

Overcharge Protection

33VDC

Maximum Charge Current

80A

Solar Charger

Maximum PV Array Power

5000W

MPPT Range @ Operating Voltage

120～450VDC

Maximum PV Array Open Circuit Voltage

500VDC

Maximum Charging Current

100A

Maximum Efficiency

98%

GENERAL

Physical

Dimension(D*W*H)

100*300*440mm

Net Weight

11kg

INTERACE

Communication Interface

USB/RS232/GPRS/WIFI

Environment

Mumidity

5% to 95% Relative Humidity(Non～Condensing)

Operating Temperature

0℃～55℃

Storage Temperature

-15℃～60℃
